SKD61 Steel Equivalent | H13 | 1.2344
- John
As we serve clients across the globe, we often receive procurement inquiries from different regions. If you are looking for equivalent materials to SKD61 steel, SteelPro Group can assist you. We not only provide SKD61 tool steel products but also offer the most professional and patient service.
What Is SKD61 Steel?
SKD61 is a premium-grade tool steel known for its great hardness, wear resistance, and thermal stability. It is widely used in mold making, die casting, and heavy-duty manufacturing, offering durability even in extreme conditions.
Overview of SKD61 Steel Equivalents
| Region | Equivalent Steel Grade |
| Japan (JIS) | SKD61 |
| GB (China) | 4Cr5MoSiV |
| Germany (DIN) | 1.2344 |
| United States (AISI) | H13 |
| International (ISO) | X40CrMoV5-1 |
SKD61 | H13 | 1.2344 Steel Comparison
Chemical Composition Comparison
| Type | C | Mn | P | S | Si | Cr | V | Mo |
| H13 | 0.32 – 0.45 | 0.2 – 0.6 | ≤ 0.03 | ≤ 0.03 | 0.8 – 1.25 | 4.75 – 5.5 | 0.8 – 1.2 | 1.1 – 1.75 |
| 1.2344/X40CrMoV5-1 | 0.33 -0.41 | 0.25 – 0.5 | ≤ 0.03 | ≤ 0.02 | 0.8 – 1.2 | 4.8 – 5.5 | – | 0.3 – 0.5 |
| SKD61 | 0.35 – 0.42 | 0.25 – 0.3 | ≤ 0.02 | ≤ 0.02 | 0.8 -1.2 | 4.8 – 5.5 | 0.8 – 1.15 | 1.5 |
Mechanical Properties Comparison
| Steel Grade | BHN (Annealed) | BHN (Cold Drawn) |
| H13 | 235 max. | 262 max. |
| 1.2344 / X40CrMoV5-1 | 229 max. | 250 max. |
| SKD61 | 229 max. | 250 max. |
Considerations When Selecting SKD61 Equivalent Steel
Cost
If you are sourcing internationally, always consider shipping costs and import fees. For example, buying SKD61 from China may offer a lower material price, but shipping fees could affect the total cost. It is crucial to consider the total expenses, not only the cost of the steel itself.
Availability
When it comes to availability, H13, and SKD61 steel are easier to find worldwide. 1.2344, on the other hand, can be harder to source quickly, especially outside of Europe.
At SteelPro Group, we ensure that SKD61 steel and its equivalent products are widely available and can be sourced quickly, no matter where you are.
Quality Control
Although SKD61, H13, and 1.2344 are all premium steels, it’s important to ensure that you select the right material for your specific requirements. Ensure the supplier provides certificates and guarantees that the steel meets your required standards.
Alternative Steel for SKD61 | H13 | 1.2344 Steel Applications
At SteelPro Group, we understand that sometimes another steel grade might be better suited for your specific needs. Here are a few alternatives to SKD61 based on different applications:
For High-Temperature Applications
For hot work applications that deal with high temperatures, H11 is a solid alternative. It provides great thermal stability and resistance to heat checking, making it ideal for high-temperature molding and forging.
For Toughness and Durability
If you need more toughness without sacrificing performance, consider D2 Tool Steel. It’s excellent for cold working tools and has a good balance of wear resistance and toughness.
Source Your SKD61 Steel From SteelPro Group
Whether SKD61, H13, 1.2344, or any other equivalent, we deliver premium materials backed by industry expertise. Thanks to our extensive global network, you can count on timely deliveries and never worry about material shortages again. Contact us today to discover how our premium steel products and expert service can drive your business forward!
