S320GD (1.0250) Galvanized Steel Sheet/Plate
S320GD (1.0250) Galvanized Steel Sheet/Plate
- Alloy or Not: Non-alloy
- Technique: Hot Rolled, Cold Rolled
- Size: As requested; details see product parameters
- Galvanization: Hot-Dip, Electro, Pre
- Condition: +HR/+CR/+A/+AR/+EG/+HDG, or as requested
- Processing Service: Cutting, Slitting, Bending, Stamping, Punching, etc.
- Certification: ISO 9001, CE
- Inspection: SGS, TUV, Factory Inspection
- Origin: Hubei/Henan/Jiangsu, China
- Port: Qingdao, Tianjin, Lianyungang
- MOQ: 5 tons (or as per negotiation)
- Delivery Time: 8-14 Days
- Payment: T/T, L/C
Product Detail
S320GD is a high-strength hot-dip galvanized low-carbon steel. The zinc coating on its surface provides added corrosion resistance and extends its lifespan. It contains elements like iron, carbon, manganese, and silicon, which give it good strength and formability.
The steel is easy to work with — it can be cut, bent, and stamped into various shapes, making it adaptable for different design and manufacturing needs. This flexibility makes it useful across a range of industries.
S320GD galvanized steel sheet/plate is commonly used in construction, automotive, and appliance sectors, especially for components exposed to harsh environments, like exterior walls, roofs, and car bodies. The zinc coating protects against moisture, acid rain, and other corrosive elements, making it ideal for areas with high humidity or fluctuating temperatures. It’s also used in light industrial machinery and outdoor equipment.
Contact us if you are unfamiliar with this product or have unanswered questions.
Features
S320GD galvanized steel sheets/plates could bring the following benefits to your project:
- No Rust – Keeps your steel rust-free for longer.
- Super Strong – Handles heavy loads and tough environments.
- Affordable – Great value for the price—long-lasting and cost-effective.
- Tough as Nails – Resists impacts and stays strong over time.
- Easy to Shape – Cuts, bends, and welds without hassle.
- Versatile – Perfect for construction, automotive, appliances, and more.
- Looks Good – Smooth, clean finish that looks sharp.
- Eco-Friendly – Coating is recyclable, supporting sustainability.
Applications
Construction
Roofing, wall cladding, structural beams, interior partitions, etc.
Automotive
Car body panels, frames, underbody parts, reinforcements, etc.
Appliances
Refrigerator panels, washing machine bodies, oven housings, air conditioner casings, etc.
HVAC
Ductwork, ventilation systems, air conditioning units, heat exchangers, etc.
Furniture
Shelving, bed frames, cabinets, office desks, etc.
Electronics
Enclosures, cabinets, chassis, mounting frames, etc.
Product Parameters
| Parameter | Details | |
|---|---|---|
| Standard | EN 10346, EN 10142, EN 10147, ISO 3575, JIS G 3302, ASTM A653 / A653M, ASTM A924 / A924M, DIN 17162, BS 1449, GB/T 2518, etc. | |
| Grade | S320GD | |
| Metal Coating Type | Z (Pure Zinc), ZF (Zinc-Iron Alloy), ZA (Zinc-Aluminum Alloy), ZM (Zinc-Magnesium Alloy), AZ (Aluminum-Zinc Alloy), AS (Aluminum-Silicon Alloy) | |
| Thickness | Sheet | 0.5-6.0 mm, or as requested |
| Plate | 6-300 mm, or as requested | |
| Width | Sheet | 600-2,000 mm, or as requested |
| Plate | 900-4800 mm, or as requested | |
| Length | Sheet | 1,000-6,000 mm, or as requested |
| Plate | 3000-32000 mm, or as requested | |
| Tolerance | ±1%, or as requested | |
| Galvanization | Hot-Dip Galvanizing, Electro-Galvanizing, Pre-Galvanizing | |
| Zinc Coating | Z30-600 g/m² | |
| Surface Structure | Regular Spangle, Minimized Spangle, Zero Spangle, Big Spangle | |
| Surface Treatment | 1) Skin Pass, Sand Blasted 2) Pre-painted 3) Galvanized 4) Oiled 5) Passivated 6) PE, SMP, PVDF, or other anti-corrosive coatings 7) As requested |
|
| Condition of Delivery | +HR/+CR/+A/+AR/+EG/+HDG, or as requested |
|
| Testing Method | CCA/MPT/CST/SST/MA/NDT, etc. | |
| Application | Roofing, wall cladding, structural beams, car body panels, underbody parts, refrigerator panels, washing machine bodies, ductwork, ventilation systems, shelving, cabinets, enclosures, etc. | |
| Certification | Approved by ISO 9001, CE | |
| Packaging | Standard seaworthy packing, or as requested | |
*Condition of Delivery: HR – Hot Rolled, CR – Cold Rolled, A – Annealed, AR – As Rolled, EG – Electro-Galvanized, HDG – Hot-Dip Galvanized
*Testing Method: CCA – Chemical Composition Analysis, MPT – Mechanical Properties Testing, CST – Coating Surface Testing, SST – Salt Spray Testing, MA – Metallographic Analysis, NDT – Non-Destructive Testing
Material Specifications
Chemical Composition
| Grade | C | Si | Mn | P | S |
|---|---|---|---|---|---|
| S320GD | ≤0.2 | ≤0.6 | ≤1.7 | ≤0.1 | ≤0.045 |
*According to EN 10346-2015.
Mechanical Properties
| Grade | Tensile Strength (σb, MPa) | Yield Strength (σs, MPa) | Elongation (δ, %) |
|---|---|---|---|
| S320GD+Z | ≥390 | ≥320 | A80: ≥17 |
| S320GD+ZF | |||
| S320GD+ZA | |||
| S320GD+ZM | |||
| S320GD+AZ | |||
| S320GD+AS |
*According to EN 10346-2015.
*The following minimum elongation values apply for different thicknesses:
- 0.5mm < t ≤ 0.7mm: minimum elongation is reduced by 2% from the values in the table.
- 0.35mm < t ≤ 0.5mm: minimum elongation is reduced by 4% from the values in the table.
- t ≤ 0.35mm: minimum elongation is reduced by 7% from the values in the table.
Why Choose Us
Consistent Quality
We address your primary quality concerns with S320GD galvanized steel sheets/plates — such as coating uniformity, potential missed spots, and coating adhesion — through continuous hot-dip galvanizing processes & strict control of temperature and timing, non-destructive thickness testing with magnetic gauges, and multi-step-pre-treatment, including acid cleaning and surface preparation, to ensure consistent performance, corrosion resistance, and long-lasting durability across various environments.
Precise Dimensions
We guarantee the dimensional accuracy of our S320GD galvanized steel sheets/plates, maintaining tight tolerances within ±0.01 mm through precision equipment and ISO 9001-certified processes. Every batch undergoes 100% inspection, with zero deviation complaints in the past 5 years. We ensure smooth project execution without installation delays.
Stable Supply
We have 3 factories with a combined annual capacity of over 500,000 tons. In the event of any unforeseen circumstances, we can coordinate across factories to ensure stable production and on-time delivery.
Stable & Competitive Pricing
We maintain upstream raw material suppliers with price-lock agreements in place to effectively manage material cost fluctuations. Also, considering that our clients may face pressure from market changes, we will try our best to offer reasonable discounts to both new and existing clients.
Secure Packaging & Shipping
Packaging can be customized according to your requirements. We provide transparent, real-time photos of the packaging and loading process for your verification. You can also choose your trusted freight forwarder for transportation to ensure the entire logistics process is secure and reliable.
About Us
Founded in 1999, SteelPRO Group operates three factories with a combined annual production capacity of over 500,000 tons. We specialize in manufacturing a wide range of steel products, including round steel, profiles, plates, and pipes. Our portfolio encompasses low-alloy structural steel, tool steel, special steel, and more.
With strict adherence to global standards such as GB, ASTM, DIN, EN, and JIS, we ensure high-quality products, including heat-treated, machined, and prestressed steel. Our solutions are trusted by customers in diverse industries, and we proudly export to different countries across Europe, North America, and Asia.
At SteelPRO, we are dedicated to delivering tailored steel solutions and growing alongside our dear clients.
