SteelPRO Group provides high-quality Q235 galvanized steel wire that meets GB, JIS, EN, ASTM and other standards, with excellent corrosion resistance and high strength. Our products use advanced galvanizing technology and are suitable for many fields such as construction, agriculture, industry and home. The steel wire can provide a variety of wire diameters and shapes, such as round and special cross-sections, and can be customized on demand, suitable for various special purposes, including high humidity environments and precision manufacturing.
- Standards: GB/T 343-1994, JIS G3548-1994, ASTM, EN, etc.
- Grades: Q235, A36, Q195, G450, G550, etc.
- Wire gauge: 8-24 gauge, 14 gauge, 16 gauge, 12 gauge, etc.
- Technology: Hot dip galvanizing, electro galvanizing
- Special Use: Marine engineering, agricultural greenhouses, electrical grounding wires, protective nets, cage, etc.
- Form: Coil, Spool, Rope, Mesh
- Certification: ISO 9001, CE
Q235 Galvanized Wire
Q235 Galvanized Wire
Product Specifications
Product Specifications
| Product Name | Q235 Galvanized Steel Wire | ||
| Wire Diameter | 0.15mm – 8.00mm, Customized | ||
| Wire Coil Weight | 20-1200kg | ||
| Wire Coil Length | Varies by coil weight, common lengths include 100 m, 200 m, 300 m, Customized | ||
| Coil Outer Diameter | 800 – 1200 mm | ||
| Coil Inner Diameter | 400 – 600 mm | ||
| Zinc Layer | 20-400g/m², g30, g40, g60, g90, Customized, etc. | ||
| Elongation | ≥15% | ||
| Tensile strength | 350 – 700 MPa | ||
| Load strength | (Depends on sight line) | ||
| Coating Material | Polyester (PE), Silicone Polyester (SMP), High Durable Polyester (HDP), Fluoropolymer (PVDF) | ||
| Surface Treatment | anti-finger print/skin pass/oiled/dry/chromated/Embossed/Lamination | ||
| Test | Zinc Coating Thickness Test, Adhesion Test, Peel, Bend, Salt Spray Test, Tensile Test, Elongation, etc. | ||
| Tolerance | ±1% | ||
| Processing Service | Bending, Welding, Decoiling, Cutting, Punching | ||
| Invoicing | By actual weight | ||
| Delivery Time | 7-15 days | ||
| Payment | T/T, L/C, Credit Card | ||
| Port | Shanghai, Qingdao or according to your requirement | ||
| Packaging Details | In bundles, in bulk, customized packing | ||
Chemical Compositions
Chemical Compositions
| Element | Carbon (C) | Silicon (Si) | Manganese (Mn) | Phosphorus (P) | Sulfur (S) |
|---|---|---|---|---|---|
| Composition (%) | ≤ 0.22 | ≤ 0.35 | 0.30 – 0.70 | ≤ 0.045 | ≤ 0.045 |
Mechanical properties
Mechanical properties
| Property | Value Range |
|---|---|
| Tensile Strength (MPa) | 375 – 500 |
| Yield Strength (MPa) | ≥ 235 |
| Elongation (%) | ≥ 20 |
| Vickers Hardness (HV) | 100 – 160 |
| Brinell Hardness (HB) | 90 – 130 |
| Rockwell Hardness (HRB) | ≤ 85 |
Industries & Applications
Industries & Applications
- Construction and Engineering: Rebar tying, structural reinforcement, fencing.
- Agriculture and Horticulture: Plant support, greenhouse frames, animal enclosures.
- Industrial Applications: Cable armoring, packaging, bundling, and hanging.
- Household and DIY Projects: Picture hanging, tool storage, light -duty shelving.
- Automotive and Machinery: Cable harnessing, temporary fastenings, mechanical supports.
- Utilities and Infrastructure: Grounding wires, utility pole supports, communication lines.
- Art and Decor: Sculpture framing, garden decor, small art installations.
Other Infomation
Other Infomation
Q235 VS Q195 galvanized steel wire
Compared with Q195 galvanized steel wire, Q235 has higher strength and hardness, making it more stable in applications, especially in occasions that require load-bearing and tensile resistance, such as building lashing, structural support, etc. Although Q195 has a slightly lower cost, its tensile strength is weaker and it is not as durable as Q235 in high-load applications. Therefore, choosing Q235 can provide higher guarantees in overall performance and service life, and is especially suitable for long-term use and outdoor environments.
Q235 VS High Carbon Steel Galvanized Steel Wire
Q235 is a low-carbon steel. Compared with high-carbon steel galvanized steel wire, Q235 performs better in flexibility. Although high-carbon steel is stronger, it is more brittle and is not suitable for occasions that require bending or frequent operations, such as gardening support and industrial lashing. Q235 galvanized steel wire strikes a balance between strength and flexibility, ensuring sufficient strength support in various applications, not easy to break, and safer and more reliable to use. In addition, high carbon steel is relatively expensive. Using Q235 can reduce material costs while meeting strength requirements, which is more economical for large procurement projects.
Our Inventory
Our Inventory
Choosing SteelPRO Group means you will get a galvanized steel manufacturer with excellent production capabilities. We have established long-term cooperative relationships with many world-renowned suppliers and partners to ensure the reliability and consistency of raw materials. SteelPRO Group has advanced production lines with an annual production capacity of one million tons, covering a variety of production, processing and manufacturing processes. Every link is strictly controlled to meet customers’ high standards for product performance and durability. We focus on improving efficiency and quality, and rely on our strong production strength to provide customers with stable supply chain support to ensure the success of various projects. Main products: Q235 galvanized steel wire, steel pipes, steel plates, steel coils, steel bars, steel strips, stainless steel series, carbon steel series, high- strength steel series, nuclear grade steel, galvanized steel, steel for wind and solar energy, etc.
Packing
Packing
We provide professional packaging solutions for each batch of products to ensure the integrity and quality of steel wire and galvanized products during transportation. The moisture-proof and rust-proof packaging, with a strong inner layer protection and outer layer reinforcement, is suitable for long -distance transportation. Our products are exported to the Middle East, South America, Africa, Southeast Asia and other regions, ensuring that our global customers receive the products in the best condition.
Our Service
Our Service
1.Welding
2.Metal Fabrication
3.CNC Machining
4.Lathe
5.Forming
6.OEM/ODM
7.Quenching
8.Tempering
Can you provide samples of your Q235 galvanized steel wire?
Yes, we can provide samples to customers for testing and verification of product quality. Please contact our sales team for sample details and application procedures.
Is Q235 galvanized steel wire suitable for long-term storage?
Yes, Q235 galvanized steel wire with rust-proof treatment is suitable for long-term storage. We recommend storing it in a dry and ventilated environment to keep the galvanized layer in the best condition.
Does SteelPRO Group support fast delivery?
Yes, we have a flexible production management and logistics network to provide fast delivery services according to customer needs to ensure that project progress is not affected.
Can SteelPRO Group customize products according to customer needs?
Yes, we can customize product specifications according to customer specific needs, including wire diameter, coating thickness and packaging methods to meet the special requirements of different projects.
What documentation support can SteelPRO Group provide?
We can provide documents such as product quality inspection reports, material certificates and certificates of compliance to ensure customer trust and understanding of the products. If necessary, please inform us when placing an order and we will provide corresponding documentation support.
What export regions does SteelPRO Group have?
Our products are exported to many regions around the world, including the Middle East, South America, Africa, Southeast Asia, etc. They are widely used in construction, agriculture and industrial projects and are deeply trusted by international customers.
