SPCC Galvanized Steel PPGI

SteelPRO Group provides high-quality SPCC galvanized steel PPGI to meet diverse market needs. We provide PPGI with a variety of coatings, surface treatments, customization, and special properties (high ductility, high strength) for applications in construction, home appliances, automobiles, furniture, and other fields. Our products have excellent corrosion resistance and weather resistance, and are durable, beautiful, and reliable in various environments. We also have galvanized steel sheets, coils, pipes, roof panels, and other grades of products.

Standards: EN 10346, ASTM A653/A653M, JIS G3302, GB/T 2518
Grades: SPCC, SGCC, DX51D+Z, CS-B, Q195, Q235
Technology: Cold rolling, Hot dip galvanizing, Passivation treatment, Pre-painted, etc.
Substrate: Cold rolled substrate, hot dip galvanized substrate, electro galvanized substrate
Type: Coated, embossed and printed boards
Certification: ISO 9001, CE

SPCC Galvanized Steel PPGI

Our SPCC galvanized steel (PPGI) is both rust-proof and beautiful, making it ideal for applications such as construction, home appliances, automobiles, and furniture. It has a uniform zinc coating and a strong color coating that is not only corrosion-resistant but also long-lasting, making it particularly suitable for outdoor and humid environments. For example, when used on roofs and exterior walls, it can withstand wind, rain, and UV rays, making the building more stylish; on the outer shells of refrigerators and washing machines, its coating is fingerprint-resistant and scratch-resistant, always keeping it neat. Our SPCC PPGI outperforms ordinary galvanized steel in quality, especially in terms of coating uniformity and weather resistance. Products from other brands tend to have coatings that fall off, especially in environments with high humidity, while our products maintain long-lasting beauty and performance even in coastal areas. In addition, the ductility of the SPCC material itself makes it smoother during molding.

Product Specifications

Product Name	SPCC Color coated galvanized steel PPGI
Thickness	0.1mm-5mm, Customized
Width	600mm – 2000mm, Customized Regular Width: 914mm, 1000mm, 1219mm, 1220mm, 1250mm
Length	Customized
Coil Inner	508mm – 610mm, Customized
Zinc Layer	30g – 275g/m²
Coating Thickness	Top Coating: 15μm-25μm; Back Coating: 5μm-20μm.
Surface Color	According to required RAL.
Coating Material	Polyester (PE), Silicone Polyester (SMP), High Durable Polyester (HDP), Fluoropolymer (PVDF)
Painting structure	No coating, single-sided coating, double-sided coating
Spangle	Big, regular, mini, and zero spangles
Surface Treatment	anti-finger print/skin pass/oiled/dry/chromated/Embossed/Lamination
Hardness	Soft (normal), hard, full hard(G300-G550)
T Bend	≧ 3 T
Reverse Impact	≧ 9 J
Salt Spray Resistance	≧ 500 H
Anti-MEK Wiping	≧ 100 Times
Tolerance	±1%
Processing Service	Bending, Welding, Decoiling, Cutting, Punching
Invoicing	By actual weight
Delivery Time	7-15 days
Payment	T/T, L/C, Credit Card
Port	Shanghai, Qingdao or according to your requirement
Packaging Details	In bundles, in bulk, customized packing

Chemical Compositions

Element	Carbon (C)	Manganese (Mn)	Phosphorus (P)	Sulfur (S)
Composition (%)	≤ 0.12	≤ 0.50	≤ 0.04	≤ 0.04

Mechanical properties

Property	Value
Tensile Strength (MPa)	270 – 370
Yield Strength (MPa)	140 – 240
Elongation (%)	≥ 28
Vickers Hardness (HV)	80 – 120
Brinell Hardness (HB)	70 – 100
Rockwell Hardness (HRB)	50 – 70
Elastic Modulus (GPa)	≈ 210

Industries & Applications

Construction Materials: Roofing and wall panels, Gutters and downspouts, Exterior facades and cladding, Ceiling and partitioning systems
Home Appliances: Outer shells for refrigerators, washing machines, and ovens, Microwave ovens and air conditioner panels, Water heater enclosures
Automotive Components: Inner and outer body panels, Structural reinforcements, Decorative trims and accessories
Furniture and Fixtures: Office furniture (cabinets, shelves, desks), Home storage units and racks, Interior and decorative applications
Electronics and Electrical Equipment: Enclosures for electrical boxes and control cabinets, Protective housings for electronic equipment, Paneling for switchboards
Advertising and Signage: Outdoor advertising boards and sign panels, Display stands and kiosks, Lightbox frames and decorative signage

Other Infomation

SPCC galvanized steel PPGI is suitable for medium humidity and temperature (-20°C to 120°C) environments and is suitable for general construction, appliance housings and light industrial use. In coastal or high humidity areas, it is recommended to use a highly weather-resistant coating (such as PVDF) to enhance corrosion resistance. For outdoor applications with strong UV rays, such as roofs and exterior walls, a weather-resistant coating can be selected to prevent fading and aging.

SPCC PPGI is not suitable for long-term exposure to extreme heat (over 120°C) or severe cold. Use in highly corrosive chemicals or heavy industrial environments may accelerate corrosion and affect service life. Therefore, more chemically resistant materials should be selected in these highly corrosive locations.

Our Inventory

SteelPRO Group is a supplier of SPCC galvanized steel (PPGI). We have modern production facilities equipped with multiple efficient production lines to ensure a stable supply of high-quality products. Through close cooperation with well-known partners, our production capacity has been further improved to a million tons per year, which can meet the large-scale needs of domestic and foreign customers. We strictly control every link of the production process, from the selection of raw materials to the testing of the final product, to ensure that all products meet high standards of quality and safety requirements.

Main products: steel pipes, steel plates, steel coils, steel bars, steel strips, stainless steel series, carbon steel series, high-strength steel series, nuclear grade steel, galvanized steel, steel for wind and solar energy, etc.

Packing

SteelPRO Group adopts strict packaging standards to ensure that each batch of SPCC galvanized steel (PPGI) is intact during transportation. Each roll of product is waterproof, dustproof, and scratch-proof, and is tightly packed with high-strength plastic film and steel straps. To meet the needs of different customers, we provide standard and customized packaging options, including wooden pallets or iron frame pallets, to ensure that the products are safe and reliable during global transportation.

Our Service

1.Welding

2.Metal Fabrication

3.CNC Machining

4.Lathe

5.Forming

6.OEM/ODM

7.Quenching

8.Tempering

Is SPCC galvanized steel (PPGI) suitable for use in high temperature environments?

SPCC galvanized steel (PPGI) is suitable for general temperature conditions, but if used in high temperature environments for a long time, the coating may be affected. We recommend using materials designed for this environment under high temperature conditions.

Can the thickness and width of SPCC PPGI be selected?

Yes, our SPCC PPGI is available in a variety of thickness and width options to meet the needs of different applications. The specific size can be customized according to your project requirements.

Are PPGI products easy to install and maintain?

Our PPGI products have good formability and lightweight characteristics, which are easy to install. At the same time, the corrosion resistance of the coating also reduces the need for maintenance, and usually only routine cleaning and inspection are required.

Does SteelPRO Group's SPCC PPGI meet environmental protection requirements?

Yes, our production process strictly follows environmental protection standards, and the coatings and materials of all products comply with relevant environmental regulations to ensure safety and harmlessness in use.

Does SteelPRO Group provide after-sales technical support?

Yes. Our technical support team is always available to answer customers’ questions about product use, installation and maintenance to ensure that you can successfully apply our products.

How to contact SteelPRO Group for bulk purchases?

You can make inquiries through our official website or contact the sales team. We will provide you with detailed quotes, product information and purchasing support, and ensure that your bulk needs are met.
